The integration between Grasshopper and Tekla Structures offers enormous opportunities for companies looking to accelerate and automate their BIM workflow. StudioFG helps organizations make optimal use of this technology—even when there is no in-house Grasshopper expertise.
The combination of Tekla and Grasshopper opens up a world of possibilities for parametric design and the automation of structural models. Even without in-depth knowledge of Grasshopper, users can generate complex configurations within Tekla Structures thanks to smart scripts and intuitive interfaces.
Parametric power for every Tekla project
StudioFG can help your organization leverage the Grasshopper–Tekla Live link connection to make design and engineering processes smarter, faster, and more consistent. Using parametric models, beams, columns, connections, or entire grid structures can be generated and adjusted with just a few settings in Tekla.
Accessible to everyone — even without Grasshopper knowledge
A major advantage of this workflow is that users do not need to be Grasshopper experts. StudioFG can develop parametric Grasshopper programs that can be loaded directly into Tekla. Examples include:
- Sliders and options to modify dimensions, variants, and positions
- Automatic generation of repetitive or uniquely complex structures
- Models that scale automatically with grid changes
- Consistent output in line with project and BIM standards
- Smart calling and adjustment of components within Tekla Structures
These tools provide a user-friendly interface that allows Tekla users to control parametric designs easily, without having to learn the complexity of Grasshopper itself.
Complex structures in seconds
Thanks to this integration, complete structures—such as trusses, canopies, stairs, prefab elements, or steel configurations—can be built automatically based on project data. The parametric scripts are smart, robust, and flexible, making them reusable across multiple projects.
Why this method is so valuable:
- Time savings: less manual drafting, more focus on engineering
- Fewer errors: parametric rules ensure consistent output
- Flexibility: changes are immediately reflected in the model
- Reusability: one script can generate dozens of variants
Together toward a smarter workflow
StudioFG develops custom Grasshopper–Tekla Structures integrations that elevate the design process. Whether it concerns repetitive tasks or fully parametric structures, we are happy to help make your BIM workflow more efficient and future-proof.
Want to learn more or discuss a potential project without obligation? Get in touch!
